For strength, beauty and whisper-quiet function, you can’t go past the ViewMaster bottom rolling bi-fold door!
- The system supports 50mm thick heavy-duty Series 50 and 52 door framing and is so strong it can carry panels up to 3000mm high.
- With stainless steel bearing rollers in a heavy-duty concealed sill track, they’re not just strong, they’re stunning and built to last.
- Surelock™ adjustment system delivers precision and the perfect fit every time.
- Choose from great lever and lock options to suit a wide variety of style and security applications and finishes.
- Rollers and pivots under the door panels are covered with a flexible silicone flap. It doesn’t just hide the mechanism but also keeps dust and water away from the rollers so they always move easily.
- Tested to resist 450Pa water, they’re suitable for any environment throughout Australia. They can also be fitted with Centor Eco Screen for a retractable and discreet barrier against creepy crawlies.
| *Maximum Frame Height and Panel Widths indicated are interdependent and subject to individual site conditions. | |
| Maximum Frame Height* | 3000mm |
| Maximum Panel Width* | 1000mm |
| Maximum Glass Thickness | ≤ 28mm |
| SHGC Range | 0.14 – 0.59 |
| Uw Range | 3.4 – 6.2 |
